Challenger Lift CS1020-04 Stop Block,3-Stage Female Arm for CL10 / CLFP9

Description

Challenger Lift CS1020-04 Stop Block,3-Stage Female Arm for CL10 / CLFP9

The CS1020-04 Stop Block,3-Stage Female Arm is a Challenger Lift service or replacement component. Use the exact part number and documented application information to confirm compatibility before ordering. Listed applications include CL10, CLFP9, CL10A.

Product Details

• Brand / Equipment: Challenger Lift
• Manufacturer / Reference Part Number: CS1020-04
• Store SKU: CHR02004
• Component: Stop Block,3-Stage Female Arm

Compatible / Referenced Equipment Models

• CL10: 10,000 lb Versymmetric two-post lift
• CLFP9: 9,000 lb floor-plate / open-top two-post lift
• CL10A: 10,000 lb adjustable-width Versymmetric two-post lift

Parts Diagram & Manual Reference

• Official Challenger CL10 parts breakdown (PARTS BREAKDOWN (continued)) identifies this as Item #89 on page 19.
• Official Challenger CLFP9 parts breakdown (Fig E. Carriage & Arms) identifies this as Item #81 on page 15.
• Official Challenger CL10A parts breakdown (PARTS BREAKDOWN (continued)) identifies this as Item #89 on page 20.

Verified Product Information

• Stop bar for the slide-arm assembly used on select Challenger lifts, including CL10 / CLFP9 applications.

Verified Part-Number Fitment

The exact part number CS1020-04 appears in verified Challenger parts documentation for the applications below:

• CL10 — Item #89, page 20: STOP BLOCK
• CL10A — Item #89, page 20: STOP BLOCK
• CLFP9 — Item #81, page 15: STOP BLOCK
• EV1020 / EV1020-QC / EV1220 / EV1220-QC — Item #22, page 17: Stop Block; Item #2, page 18: Stop Block
• EW1020 / EW1020-QC / EW1220 / EW1220-QC — Item #15, page 18: Stop Block; Item #2, page 20: Stop Block

Compatible Makes & Models

Compatible makes / equipment brands:

• Challenger

Verified fitment models include:

• CL10
• CLFP9
• CL10A
• EV1020
• EV1020-QC
• EV1220
• EV1220-QC
• EW1020
• EW1020-QC
• EW1220
• EW1220-QC

Fitment can vary by production date, serial range, lift configuration, and equipment revision. Match the manufacturer/reference part number and your specific model before ordering.

Fitment & Ordering Notes

Challenger Lift components can vary by model, serial-number range, production date, lift height, side or orientation, color, power-unit configuration, and equipment revision. Before ordering, compare the manufacturer part number, specifications, diagram callout, model information, and original component. A similar appearance alone does not confirm interchangeability.
