E15 Carriage

Drawing Number

Parts Description

24 Available Parts

Carriage

$2,028.38

Slide Block

$20.00

Arm Pin

$51.99

Unnamed part

—

Unavailable online – please call for availability.

M8 Washer

$0.42

M8 x 30mm Lg. Socket Head Bolt

$2.77

M10 x 25mm Lg. Socket Head Bolt

$3.17

Unnamed part

—

Unavailable online – please call for availability.

Inner Gear

$68.80

Arm Restraint Shaft

$10.79

Arm Restraint Spring

$11.65

Outer Gear

$58.08

Arm Assembly

$1,220.58

18 MM dia. Plastic Plug

$2.35

100

Unnamed part

—

Unavailable online – please call for availability.

101

40.5 x 48 x 20mm Lg. Collar

$3.98

102

M8 x 8mm Set Screw Cup Point

$0.40

103

M8 x 12mm Lg. PPHS

$7.26

104

Carriage Cover

$17.58

105

Foot Pad Assembly

$1,844.89

105A

Unnamed part

—

Unavailable online – please call for availability.

105B

Adapter Pad Weld

$111.30

105C

3 x 45mm Retaining Ring

$0.89

105D

Unnamed part

—

Unavailable online – please call for availability.

E15 Carriage

Drawing Number

Parts Description

Carriage

Slide Block

Arm Pin

Unnamed part

M8 Washer

M8 x 30mm Lg. Socket Head Bolt

M10 x 25mm Lg. Socket Head Bolt

Unnamed part

Inner Gear

Arm Restraint Shaft

Arm Restraint Spring

Outer Gear

Arm Assembly

18 MM dia. Plastic Plug

Unnamed part

40.5 x 48 x 20mm Lg. Collar

M8 x 8mm Set Screw Cup Point

M8 x 12mm Lg. PPHS

Carriage Cover

Foot Pad Assembly

Unnamed part

Adapter Pad Weld

3 x 45mm Retaining Ring

Unnamed part
