Forward Lift 912671 Hex Head Cap Screw 1/2"-13 x 1-3/4" Grade 5 Plated for DP10, DP97S2 Leg Brace / Bolt Box

Description

Forward Lift 912671 Hex Head Cap Screw 1/2"-13 x 1-3/4" Grade 5 Plated for DP10, DP97S2 Leg Brace / Bolt Box

Replace missing, worn, or damaged lift hardware with the 912671 Hex Head Cap Screw 1/2"-13 x 1-3/4" Grade 5 Plated, listed for use on DP10, DP97S2 Leg Brace / Bolt Box. This hardware is used when servicing the specified Forward Lift assembly. Match the part number, size or description, and listed application before ordering.

Product Information

• Brand / Equipment: Forward Lift
• Manufacturer / Reference Part Number: 912671
• Store SKU: FOD2671
• Component: Hex Head Cap Screw 1/2"-13 x 1-3/4" Grade 5 Plated
• Listed Application: DP10, DP97S2 Leg Brace / Bolt Box

Fitment & Ordering Notes

Automotive lift manufacturers may use different parts across model years, production runs, or equipment revisions. Before ordering, compare the reference part number and the model/application information in this listing with the identification tag, parts manual, or original component on your lift. If your equipment uses a different part number, verify interchange before installation.

Additional Existing Product / Fitment Information

In the drawing images above this is part number 36 in the DP10-Parts new style w lock covers drawing and part number 85 in the DP97S2 drawing and part number 36 in the I10N000M drawing.

Fits the following lift models — part number 912671 appears in the parts breakdown of each of these lifts: Rotary Lift DP10 (new style with lock covers), I10N000M; Forward Lift DP97S-2, INT9, DP9A-S, 12000LR/LRD 12K, 12500ARO Open-Front, DP97S-2 Two-Post, DP10 10K Two-Post; 12K SAR/LAR/SWT/EW Four-Post.

This Grade 5 plated hex head cap screw is identified in the factory breakdowns as the leg brace bolt and appears in the 12000 EWT Parts Breakdown, Bolt Box P/N 994034, and Figure 17. The breakdown also lists it in a 16-pack configuration for 2-step, 24-ball support hardware.

OEM replacement from the Forward Parts family. Verify the 1-3/4″ length against your figure callout, as these lifts use 1/2″-13 bolts in multiple lengths and grades depending on the joint.
