Description
SPX Stone AB-9367 Hydraulic Power Unit for Challenger CL10 CL10v3 Car Lift
When the hydraulic power unit on your Challenger CL10 series 2-post lift requires replacement, this USA-made SPX Stone unit delivers a complete assembly including the tank, pump, motor, and switch. Before ordering, confirm your lift runs on 208-230V single-phase power and check whether your power unit includes a limit switch that must be transferred to the new unit.
Product Information
- Brand / Manufacturer: SPX Stone (Fenner)
- Manufacturer / Reference Part Number: AB-9367
- Challenger OEM Reference: A1201-17
- Store SKU: SP10AH
- Component: Complete Hydraulic Power Unit (tank, pump, motor, switch)
- Voltage: 208-230V single phase, 60 Hz
- Motor: 2 HP, 3450 RPM (3.5 HP torque equivalent)
- Flow Rate: 2.1 GPM
- Tank Capacity: 4 gallons
- Certification: ETL Certified, Made in USA
- Fluid Compatibility: Standard hydraulic oil or Dexron II transmission fluid
- Listed Application: Challenger CL10, CL10v3, CL10V3-3
Replacement / Cross-Reference Numbers
- AB9367, AB1270, 17300001
- Replaces Challenger AB-9367, Challenger A1201-17
Fitment & Ordering Notes
This unit can replace Fenner, SPX, Stone, MTE, WEG, and Monarch brand power units. The pump outlet can be positioned on either side to match your existing pressure-line routing. A universal mounting bracket is included. Always verify fitment before ordering by calling 866-902-6060.
Additional Product Information
WARNING: Replacing the hydraulic power unit does not increase the rated capacity of the lift. Never exceed the rated capacity – structural failure will occur.
