Direct Lift PP8+ Long Crossbeam Assembly

Drawing Number

Direct Lift PP8+ Long Crossbeam Assembly parts breakdown drawing

Parts Description

31 Available Parts

6

Crossbeam Weldment

Crossbeam Weldment

$592.70

18

Nut M8

Nut M8

$14.53

19

Lock Washer Ø 8

Lock Washer Ø 8

$14.53

20

Flat Washer Ø 8

Flat Washer Ø 8

$14.53

31

Flat Washer Ø 20

Flat Washer Ø 20

$15.57

38

Cable Pulley

Cable Pulley

$70.00

47

Small Cable Pulley

Small Cable Pulley

$22.84

53

Hex Head Bolt M8x35

Hex Head Bolt M8x35

$14.53

54

Hex Head Bolt M8x20

Hex Head Bolt M8x20

$14.53

55

Lock Plate

Lock Plate

$16.61

56

Slider

Slider

$33.22

57

Shaft

Shaft

$16.61

58

Pulley Cover

Pulley Cover

$47.75

59

Set Screw M8x10

Set Screw M8x10

$14.53

60

Bushings

Bushings

$15.57

61

Cable Pulley Pin

Cable Pulley Pin

$47.75

62

Flat Washer Ø 24C Level

Flat Washer Ø 24C Level

$14.53

63

Spring

Spring

$23.87

64

Work Lock

Work Lock

$26.99

65

Spring

Spring

$23.87

66

Work Lock

Work Lock

$15.57

67

Spring

Spring

$15.57

68

Spacer

Spacer

$26.99

69

Lock Shaft

Lock Shaft

$47.75

70

Work Lock

Work Lock

$26.99

71

Spring

Spring

$15.57

72

Safety Lock

Safety Lock

$20.76

87

Flat Washer Ø 6

Flat Washer Ø 6

$14.53

89

Discal Head Screw M6x10

Discal Head Screw M6x10

$14.53

101

Hex Head Bolt M8x40

Hex Head Bolt M8x40

$15.57

102

Nylon Lock Nut M8

Nylon Lock Nut M8

$14.53

Factory parts breakdown for the Direct Lift PP8+ Long 8,000 lb four-post lift Crossbeam Assembly (Figure #2). Covers the crossbeam weldment, slack safety weldments, latch dogs, sheaves, cable guards, bushings, springs and mounting hardware.

Match the numbered callouts in the drawing to the parts list below to find the exact replacement crossbeam component for your PP8+ Long.
